EV-300

For skid steer loader
For articulated loader
For tractor front loader
For tractor backlift
Min oil flow:
30 L/Min
Max oil flow:
75 L/Min
Max Pressure:
210 Bar
Suited for:
Beets, Potatoes, Maize/corn, Concentrates, TMR, Pressed pulp
Loader brackets:
Welded

Auger Bucket for pressed pulp, maize, concentrates, beets, ... -> 1 side exit

The EV-300 feed bucket is suitable for feeding (optional also mixing) short or dry products such as (silage) maize, pulp, concentrates, beetroot, potatoes, carrots, etc. An additional stirring auger prevents bridging above the distribution auger. The machine is hydraulically driven and fits on a shovel as well as on a tractor. Optionally, a beet or potato blade can be provided for cutting root crops. The bucket can be provided with a door at the exit that prevents feed from falling out during transport.

As standard, the machine has straight sides. The exit tube will stick out +/- 25cm. If, for example, a trench silo has to be shovelled, the option ‘extended side’ is recommended.

At the customer’s request, the bucket can be equipped with a claw on top of the bucket to pull the feed into the bucket.

Standard

  • Distribution of maize and concentrates
  • Chopping of beets and potatoes = option
  • 1 Auger Ø300 x 6 – 8 and at exit 10mm thick
  • Driven by hydraulic motor and single chain 1″ reinforced on hardened sprockets
  • Plate thickness 5 and 8 mm
  • Exit tube 8 mm thick
  • Exit left OR right
  • Stirring auger prevents bridging above the distribution auger
EV-300 / 1300 EV-300 / 1500 EV-300 / 1700 EV-300 / 1900 EV-300 / 2100 EV-300 / 2300 EV-300 / 2400
Scoop width /m 1,05 1,25 1,45 1,65 1,85 2,05 2,15
Total width /m 1,30 1,50 1,70 1,90 2,10 2,30 2,40
Volume /m³ 0,66 0,80 0,93 1,07 1,21 1,35 1,42
Weight /kg 430 440 510 530 550 570 600
Possible 3 point linkage for tractor? No No No No Yes Yes Yes
Price (excl. VAT) On request On request On request On request On request On request On request



Options

  • Extended side for easy scooping next to a wall (scooping width will be equal to total width)
  • 3 point linkage for tractor (not possible at all widths, see table above)
  • Mechanical door closure on exit
  • Hydraulical door closure on exit
  • Beet- or potato blade - complete
  • Beet- or potato blade - supplied loose, without counter blade
  • 2-cylinder-clamp
  • 4-cylinder-clamp
  • Milling rotor clamp
  • Mixing auger instead of stirring auger
