Stable Boy
For skid steer loader
For articulated loader
For forklift
30 L/Min
60 L/Min
175 Bar
Straw, Hay
Bolted
Vertical straw and hay distributor for loaders from 1000kg to 3000kg
VDMJ has been the specialist in all kinds of straw bedding machines for more than 20 years. After the development, production and sale of bedding machines for cowsheds, poultry houses, goat barns, etc. it is now the turn of the horse stables! With the Stable Boy, VDMJ is introducing a unique machine to the market, which has rapidly attracted an incredible amount of attention from horse owners all over the world. This is because the machine offers many advantages, such as faster working, less intensive work, both straw and hay can be distributed, straw saving and much more.
With the specially developed construction, the VDMJ team has succeeded in building a robust machine that is nevertheless very light. This makes the Stable Boy perfect for use with small loaders with a minimum lifting capacity of 500 kg or more (such as Avant, Norcar, Schaffer, Weidemann, Giant, Multione, Gehl, Eurotrac, Pitbull, Bobcat, JCB, Kubota, Thomas, ….).
The Stable Boy is available in 2 versions:
– unloading at the bottom, without conveyor belt (empty weight +- 400 kg)
– left and right unloading, with conveyor belt (empty weight +- 580 kg)
In addition to horse husbandry, the Stable Boy is also frequently used at livestock farms. For example, it is used to spread straw in cubicles.
Standard
- Recommended for loaders with a deadweight of less than 3 tons
- Straw/hay falls out of the machine at the bottom over a width of +/- 1,40m
- 2 unloading rollers
- As standard without hydraulic drain line
| Width /m | 1,50 |
| Height without conveyor belt /m | 1,66 |
| Height with conveyor belt /m | 2,25 |
| Weight without conveyor belt /kg | 400 |
| Weight with conveyor belt /kg | 580 |
| Max. dimensions square bales W x H x L /m | 1,20×0,90×1,25 |
| Price (excl. VAT) | On request |
Options
 | Conveyor belt |
 | Throw unit left side (for spreading 3m to 6m distances) - only in combination with conveyor belt |
 | Quick-change system (to quickly connect and disconnect conveyor belt under the machine) |
 | Hydraulic drain line (=3th connection) - recommended with conveyor belt option |
 | Lowered scoop section (load length 1.00m, weight -40kg, height -30cm) |
